COMMELL HS-773 User Manual
Page 15
HS-773 User’s Manual
-
13
-
2.4
2.4.1
The board comes with the socket rPGA988 for Intel
Sandy Bridge
Processor, Please
follow the instructions to install the CPU properly.
1. Use a slotted screwdrive to
unlock the CPU socket
Unlock way
2. Follow the pin direction to install
the processor on the socket
3. Lock the socket
Socket CPU
Check point
