HS-B70 User’s Manual

1.2

General Specification

Form Factor

PICMG 1.3 Half-size CPU Card

CPU

Generation Intel® Core™ i7, Core™ i5, Core™ i3 Mobile Processor

Package type: rPGA988B

Memory

2 x DDRIII SO-DIMM 1066/1333/1600 MHz up to 16GB

Support Non-ECC, unbuffered memory only

Chipset

Intel QM77

Real Time Clock

Chipset integrated RTC with onboard lithium battery

Watchdog Timer

Generates a system reset with internal timer for 1min/s ~255min/s

Power Management Supports ACPI 3.0 compliant,

DVI Interface

Onboard DVI connector interface

LVDS Interface

Onboard 24-bit dual channel LVDS connector with +3.3V/+5V/+12V

supply

Serial ATA Interface 2 x serial ATAII interface with 300MB/s transfer rate

2 x serial ATAIII interface with 600MB/s transfer rate

Support RAID 0, 1, 5, 10 and Intel Rapid Storage Technology

Audio Interface

Realtek ALC888 HD Audio

LAN Interface

1 x Intel 82579LM Gigabit LAN

(Support iAMT8.0)

1 x Intel 82574L Gigabit LAN

GPIO interface

Onboard programmable 8-bit Digital I/O interface

Extended Interface

PICMG 1.3 Half-size Interface Support 1 PCI-Express x16

、1 PCI-Express x4 or 4 PCI-Express x1 and 1 x PCIE mini card socket

(Optional support mSATA

(SATAII)

for Mini_Card)

Internal I/O Port

5 x RS232, 1 x RS232/422/485, 1 x SMBUS, 1 x GPIO, 4 x USB3.0 ports,

2 x USB2.0 ports, 1 x IrDA, 1 x DVI, 1 x LVDS, 2 x Serial ATAII,

2 x Serial ATAIII, 1 x Front panel Audio and 1 x CDIN

External I/O Port

1 x VGA Port, 2 x RJ45 and 1 x PS/2 Keyboard/Mouse Port

Power Requirement

+12V , 5VSB & 3VSB from Backplane

Dimension

168mm x 126mm

Temperature Operating within 0~60 centigrade

Storage within –20~85 centigrade

Ordering Code

HS-B701

Intel PGA988B + QM77 Onboard VGA, LVDS, DVI, LAN, USB2.0,

USB3.0, HD Audio, SATAII ,SATAIII, SMBUS, LPC, IrDA, GPIO,

PCI Express mini card and

mSATA

Support

Four X1 & One X16

PCI Express interface

HS-B704
