FS-97D User’s Manual Hardware Setup

Connector Reference

15

2.3

2.3.1

Connector

Function

Remark

CPU

LGA775 CPU socket

DDRII1/2

240 -pin DDR2 SDRAM DIMM socket

FDD

34-pin floppy connector

CN_LPT

13 x 2-pin LPT connector

S_ATAI1/2/3/4/5/6 7-pin

Serial ATA II connector

CN_12V

8-pin +12V additional power supply connector

CN_AUDIO

5 x 2-pin audio connector

CDIN

4-pin CD-ROM audio input connector

CN_PS

3-pin ATX function connector

DC_IN

4-pin power supply connector

CN_DIO

6 x 2-pin digital I/O connector

CN_USB1/2/3/4

10-pin USB connector

CPUFAN

4-pin CPU cooler fan connector

SYSFAN

3-pin system cooler fan connector

CN_IR

5-pin IrDA connector

CN_ATKB

5-pin AT keyboard connector

CN_INV

5-pin LCD inverter connector

FS-97DXG

CN_LVDS

20 x 2-pin LVDS connector

FS-97DXG

JFRNT

14-pin front panel switch/indicator connector

Mini-PCI

1 x 124-pin Mini-PCI socket

CN_DVI 26-Pin

connector

FS-97DDG

CN_COM1/2

5 x 2-pin com connector

2.3.2

Connector

Function

Remark

CRT VGA

connector

RJ45_1/2

One/Two RJ45 LAN connector

PS2

PS/2 keyboard and mouse connector
