2.3
2.3.1
Connector
Function
Remark
CPU LGA1155
CPU
socket
DDRIIIA&B
240 –pin DDR3 SDRAM DIMM socket
SATA 1/2
7-pin Serial ATAIII connector
SATA 3/4/5/6
7-pin Serial ATAII connector
CN_12V
4-pin +12V additional power supply connector
CN_AUDIO
5 x 2-pin audio connector
CDIN
4-pin CD-ROM audio input connector
CN_DIO
6 x 2-pin digital I/O connector
CN_USB 1/2
5 x 2-pin USB connector
CN_USB 3_1/2
10 x 2-pin USB connector
CPUFAN
4-pin CPU cooler fan connector
SYSFAN
4-pin system cooler fan connector
CN_IR
5-pin IrDA connector
CN_COM1/2/3/4/5/6
9-pin com connector
JFRNT
14-pin front panel switch/indicator connector
Mini-Card1/2
2 x 52-pin Mini-PCIE socket
CN_LPT
13 x 2-pin printer connector
JSPD 1/2
LAN Speed LED connector
JACT 1/2
LAN Activity LED connector
CN_DVI
13 x 2-pin DVI connect
2.3.2
Connector
Function
Remark
RJ45 1/2
1 x RJ45 LAN connector
CRT
DB15 and analog VGA connector
PS/2
PS/2 keyboard and mouse connector
(FS-A76G2 & FS-A76FG2)
(FS-A76G & FS-A76FG)
Connector
Function
Remark
RJ45 1
1 x RJ45 LAN connector
CRT
DB15 and analog VGA connector
PS/2
PS/2 keyboard and mouse connector
COM1
1 x DB9 connector
