13 GB
Operation / Cleaning and maintenance
q
Switch the Power Manager
on / off
i Set the master ON / OFF switch 1 to position
I to switch the Power Manager on.
i Set the master ON / OFF switch 1 to position
0 to switch the Power Manager off.
Note: If the Power Manager is switched off,
all connected appliances are also switched off
automatically.
q
Switch electric appliances
on / off
i Make sure that the Power Manager is switched
on (see “Switch the Power Manager on / off “).
i Set the respective ON / OFF switch 3 to position
I to switch the connected appliance on. The
respective ON / OFF switch
3 lights up if the
connected appliance is on.
Note: Socket and respective ON / OFF switch
3 are arranged in the same order.
i Set the respective ON / OFF switch 3 to posi-
tion 0 to switch the connected appliance off.
q
Use of the USB hub
(only for PMA USB DE V2)
i First connect the type-B USB jack (square) of
the USB line (included) with the connection
socket
6 .
i Connect the other end of the USB line with the
USB port of your computer.
i Now connect the type-A USB jack (flat) of the
respective appliance with one of the 4 USB
ports
4 . Now you can use the Power Manager
as USB hub for your computer.
q
Power adaptor for USB hub
(only for PMA USB DE V2)
It is possible to externally supply the USB hub with
electricity using a power adaptor (not included).
This may be necessary for the use of specific USB
devices.
i Plug the connection of the power adaptor
(5 V / 2.5 A DC
) (not included) into
the power adaptor socket 5 .
i Plug the power plug of the adaptor into a
properly installed outlet.
i Disconnect the adaptor from the adaptor socket
5 when the adaptor is not connected to the
mains.
q
Surge protection
The Power Manager has an integrated surge pro-
tection (19.500 A), which protects the connected
electric appliances from voltage peaks (e.g. indirect
lightning).
- The surge protection is active when the LED 2
is on.
- The surge protection has been destroyed, if the
LED 2 remains dark when the Power Manager
is switched on. The power supply to the sockets
7 is cut.
q
User information
- You can use the body of the Power Manager
as support for various appliances (e.g. notebook,
TFT display etc.) (see figure C).
Q
Cleaning and maintenance
ELECTROCUTION HAZARD!
Keep the device away from rain and moisture. Ingress
of moisture increases the risk of electric shock.
