This list contains replaceable parts used in your heater. When ordering parts, follow
the instructions listed under Replacement Parts on page 26 of this manual. PARTS LIST
Model CGP26D
PARTS AVAILABLE - NOT SHOWN
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098304-01 Screw, #10 x 3/8" 2
2 098742-04 Front Panel 1
3 098238-07 Grill Guard 1
4 098342-01 Clip-Grill Guard 2
5 098198-04 Apron 1
6 M11084-26 Screw, #10 x 3/8" 9
7 098462-01 Control Rod Assembly 1
8 098457-02 Reflector Assembly 1
9 098867-06 Regulator 1
10 M11084-38 Screw, #8 x 3/8" 2
11 098456-01 Cabinet Assembly 1
12 098324-01 Control Knob 1
13 See Detail Burner Assembly 1
13-1 099218-02 Burner 1
13-2 098508-01 Valve Retainer Nut 1
13-3 099056-01 Injector 5
13-4 099052-01 Tubing-Valve to plaque B & D 1
13-5 099053-01 Tubing-Valve to plaque C 1
13-6 099057-01 Pressure Tap Fitting 1
13-7 099054-01 Tubing-Valve to plaque A & E 1
13-8 098932-06 Control Valve 1
13-9 099051-02 Inlet Tubing 1
13-10 099044-01 Pilot Tubing-Valve to pilot 1
13-11 099059-02 ODS/Pilot 1
13-12 M11084-37 Screw, #8 x 1/4" 5
13-13 M11084-26 Screw, #10 x 3/8" 2
13-14 098593-01 Thermocouple 1
13-15 098594-01 Ignitor Electrode 1
14 099066-01 Mounting Bracket 1
098465-01 Control Position Label 1
100642-01 Assembly, Hardware 1
