SUPPORT RESOLUTION
VGA INPUT/OUTPUT HDMI OUTPUT
PC SD/HD PC
480I/576I (NTSC/PAL) v v
480P/576P v v
720P@(50/60) v v
1080I@(25/30) v v
1080P@(50/60) v v
VGA@(60/72/75/85) v v
SVGA@(56/60/72/75/85) v v
XGA@(60/70/75/85) v v
SXGA@(60/75/85) v v
UXGA@60 v v
WXGA@60(1280x800) v v
WSXGA@60(1680x1050) v v
WUXGA@60(1920x1200) v v
Note: If PC connected to the VGA input, local output will only support PC resolutions. If HD/SD source connected to the
VGA input, local output will support only HD/SD resolutions.
RESETTING THE UNIT
1. Press and hold “Menu” button for 5 seconds
2. Disconnect power plug from the unit while holding the “Menu” and wait for 5 seconds
3. Connect the power plug back in and continue holding the “Menu” for another 5 seconds
4. Release the “Menu” and allow up to 10 seconds for the unit to connect to the display
