REMOTE CONTROL
Ensure the mains voltage supply matches the label on the supplied plug-Pack (+/- 10%)
Ensure that the power switch is OFF
Connect all audio video sources and destination equipment
Power up all HD Source and Displays
For each desired output select the appropriate input by using the front panel select buttons or IR remote control
When powering up the AT-HD-V112 will return to its last used setting before Powered down
1,2 SWITCH POWER ON or OFF
IR EXTENDER
1. IR Extender Connection
