2. Rear Panel
1. DC POWER INLET. Power input -12VDC
3. INPUT-1x HDMI
HDMI (Female) digital video/audio connector
Note: With the proper adapters, the distributor can be used with DVI digital video signals
2,4. OUTPUTS: HDMI Outputs 1-8.
HDMI (Female) digital video/audio connector Note: With the proper
adapters, the distributor can be used with DVI digital video signals
APPLICATIONS
HDMI Displays 5-8 HDMI Displays 1-4
1 2 3 4
HDMI Player
