3 www.atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
AT-HDKVM-V21 AT-HDKVM-V41
Inputs 2 x HDMI, 2 x USB (type B) 4 x HDMI, 4 x USB (type B)
Outputs 1 x HDMI, 2 x USB (type A), 2 x PS2 1 x HDMI, 2 x USB (type A), 2 x PS2
Frequency bandwidth 6.75Gbps
Resolutions up to 1080p
Color Depth up to 48bit
HDCP Compliant Yes
Power Supply 5v DC (universal 110/220v)
Dimensions (W x D x H) 5.11”x2.9”x1.65” /
130x75x42(mm) 7.87”x2.9”x1.65” / 200x75x42mm
Weight 1.1LB / 0.5kg 1.4LB / 0.65kg
Operating Temperature Range -5 to +35°C (-41 to +95 °F)
Storage Temperature Range
-20 to +60°C
Operating Humidity Range 0 to 80 % RH (no condensation)
1. Connect HDMI Cable from your computers to inputs on the Atlona HD KVM Switch
2. Connect the one USB cable to each one of the computers. Make sure that HDMI input numbers corre-
spond with USB input numbers. The USB connections for the computers are located at the back side of
the switcher.
3. Connect HDMI cable from the output of the switch to the HDMI input on the display.
4. Connect Keyboard and Mouse to the outputs of the switch. User can choose to use either USB or PS2,
mix and match is acceptable.
5. Connect the switch to the included power supply and enjoy
6. User can choose to use manual front button input selection or Hot Key selection.
SPECIFICATIONS
CONNECTION AND OPERATION
