Introduction
Atlona AT-HDMI-31 is a high performance HDMI switcher
with remote control. It allows your various HDMI sources to
share one HDTV display.
Simply pressing one button to select your desired HDMI source
for display on the HDTV.
Features
* HDMI 1.1, HDCP 1.1 and DVI 1.0 compliant.
* Signal Enhancement feature allows you to improve signal quality
after long distance transmission.
* LED indicators.
* Ideal for home theater integration.
* Supports high resolution input:
PC: VGA, SVGA, XGA, SXGA, and UXGA (1600 x 1200)&
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i, and 1080p
* Remote control.
* Easy to install and simple to operate.
Operation Controls and Functions
Front Panel
INPUT 1 2 3 POWER
SIGNAL ENHANCE
Switcher
HDMI-31
3x1
HDMI
1 2 3 4 1 2 3 4
1. Remote control sensor.
2. Input select/Indicators: Press the " INPUT" button sequentially to switch to your
desired input source and the LED will illuminate to indicate which
input source is selected.
3. Signal Enhancement/Indicator: Press the " Signal Enhance" button to turn
on this feature to improve signal quality after long distance transmission.
Press again to turn off. The LED will illuminate when the signal is enhanced.
4. Power LED Indicator: The LED will illuminate when the power is connected.
