SPECIFICATIONS
Transducer Low:
10" woofer with 1.5" voice coil
Transducer High: 1" titanium diaphragm compression driver
Output Power: 200 W Continuous (135 W LF + 65 W HF)
400 W Peak (270 W LF + 130 W HF)
Frequency Range: 51 Hz – 20 kHz (@ -10 dB)
Frequency Response: 52 Hz – 20 kHz (+3 dB)
Max SPL @ 1m: 123 dB Continuous
126 dB Peak
Nominal Horn Coverage: 80/100° H x 60° V nominal (-6 dB)
Active Crossover: 2.5 kHz
Connectors: 1 Mic/Line XLR -1/4" combo inputs
1 stereo pair of RCA inputs
1 XLR mix output
External Controls: Input volume, dock volume, power switch with LED indicator,
signal/peak LED indicator, contour switch, output mode switch
Input Control: - ∞ to +50 dB (Line/Mic)
- ∞ to +10 dB (RCA)
- ∞ to +10 dB (Dock)
Cabinet: Trapezoidal with floor monitor capability; injection-molded polypropylene
enclosure with perforated steel grille
Mounting: Integrated pole socket (36 mm diameter)
1 handle
Protections: Over-excursion, thermal, driver, DSP-based
Power supply: 100 VAC, 110-120 VAC, 220-240 VAC; 50/60 Hz
Inrush current at initial switch-on: 0 A
Inrush current after power supply interruption: 2.20 A
Dimensions (H x W x D): 20.2" x 13" x 11.4" (513 mm x 330 mm x 290 mm)
Weight (speaker only): 26.6 lbs (12.1 kg)
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2)
THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
