Specifi cations—FSL Flatscreen Lift
FSL Flatscreen Lifts, model (FSL-F-42/FSL-F-50/FSL-F-65) .
Flatscreen Lift for installation on a ¾" thick back panel, such as plywood,
MDF or other stable material. Lift shall utilize a universal mounting option and
easy “drop-in” installation into cabinetry or furniture. Secondary shelf beneath
the display to facilitate attachment of a matching trim piece to fi ll most of the
opening left by the open cabinet lid for a clean, fi nished appearance when
raised.
24V DC motor shall have operating noise level of approximately 63 dB (when
not installed in furniture) and shall stop automatically if motor current is over-
loaded. Lift shall automatically switch to “creep” mode as it approaches “up”
and “down” limits to prevent vibration of display during operation. Limits can
be adjusted to stop at any intermediate point for “up” and “down” positions.
Power Surge Line Overload Protection provided to protect fl atscreen display
from power surges.
Extended height of lift approximately 2.5 times stored height of fl atscreen.
Patented (U.S. Patent No. 7,128,003). Other Patents Pending.
Downloadable 3-part specifi cations available at www.draperinc.com.
Electrically Operated
Flat Panel Lift
FSL Flatscreen Lift
by
Copyright © 2008 Draper Inc.
Form FSL_Sub08
Printed in U.S.A.
PROJECT:
ARCHITECT:
CONTRACTOR:
SUPPLIER:
DATE:
REVISED:
®
Please Mark Appropriate Selections
Select Model :
FSL-F-42
FSL-F-50
FSL-F-65
Optional Accessories:
Cable Management System
Control Options:
Please Note: This product is provided with a controller and Radio Frequency
Remote as standard. For optional IR, or RS232 input, please select below.
Optional Controller with InfraRed Remote and RS232 Input
Dimensions and Data
Model
FSL-F-42
FSL-F-50
FSL-F-65
TV Size
Up to 42"
Up to 50"
Up to 65"
Maximum
TV
Height*
24
13
/
16
" 28¾" 34¼"
Lift
Height
25
13
/
16
" 29¾" 35¼"
Lift
Width
17"
17"
17"
Lift Depth without Brackets
3
1
/
16
" 3
1
/
16
" 3
1
/
16
"
TV Bracket Depth
1"
1"
1"
Lift Depth with Brackets**
4
1
/
16
" 4
1
/
16
" 4
1
/
16
"
Lift Height at Max. Ext.
59¼"
73½"
83
5
/
8
"
Extension
33
7
/
16
" 43¾" 48
3
/
8
"
Extension Time
25 sec.
33 sec.
36 sec.
Max. Weight Capacity
210 lb
210 lb
210 lb
Lift Net Weight***
67 lb
75 lb
84 lb
*If using secondary shelf, and TV height is a concern, contact Draper for
recommendations.
**Back-panel to back of TV.
***Not including cabinetry or structure provided by others.
Dimensions
Dimensions—with Extensions
B
20
1
/
2
"
32"
17"
3
1
/
4
"
3
1
/
16
"
15
/
16
"
2
3
/
16
"
20"
8
13
/
16
"
A
Model
Dim A Dim B
FSL-F-42 25
13
/
16
" 42"
FSL-F-50 29
3
/
4
" 46
1
/
16
"
FSL-F-65 35
1
/
4
" 63"
Model
Dim C Dim D
FSL-F-42 59
1
/
4
" 25
3
/
8
"
FSL-F-50 73
1
/
2
" 29"
FSL-F-65 83
5
/
8
" 30
9
/
16
"
C
D
