DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU 4350PE512
BRAND HD 4300
May 4, 2009 - 4:13 pm ENG APVD - LK 2008-06-03
MRKTG APVD - LL 2008-08-21
SKU 4350PE512
PRODUCT DIAMOND ATI Radeon™ HD 4350 PCIE 512MB DDR2 Video Card
PRODUCT SHORT DESCRIPTION INTERFACE PCI Express x16
GPU HD 4350
CORE CLOCK 600 MHZ
MEMORY CLOCK 800 MHz
MEMORY CONFIGURATION 8Mx32
MEMORY TYPE DDR2
MEMORY BANDWIDTH 52.6 GB/sec
MEMORY SIZE 512MB
MEMORY CONTROLLER INTERFACE 64-Bit
PORTS DVI,S-Video,VGA
DUAL LINK DVI Hydravision 4
PRODUCT DETAILED DESCRIPTION ATI Avivo™ HD Video & Media
The ATI Radeon HD 4300 Series of GPUs enable you to experience the power of HD with graphics processing designed
for entertainment and productivity. Watch Blu-ray and HDDVD videos in full 1080p HD – Play the next generation of HD
games featuring life-like realism from DirectX® 10.1 compatibility and easy ATI CrossFireX™ multi-GPU upgradeability.
Enjoy breakthrough through efficiency from cutting-edge technology and new energy-saving features that help you save
money and enable cooler, quieter PCs.
PRODUCT FEATURES
● GPU: Radeon™ HD4350
● Bus Type: PCI-Express
● Core Clock: 600Mhz
● Memory Size: 512MB
● Memory Configuration: 8Mx32 DDR2
● Memory Interface: 64-Bit
● Memory Speed: 800 Mhz
● Dual Link DVI + SVideo + VGA (7.1 sound supported via HDMI dongle/adapter)
SYSTEM REQUIREMENT EXTERNAL POWER REQUIREMENT NONE
CPU Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher
CPU SPEED 2.0 Ghz or faster
MEMORY 1024MB
HARD DISK 480MB available hard disk space
SYSTEM BUS PCI Express x16
SLOT SINGLE
CHASSIS N/A
MONITOR Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor
INTERNET ACCESS N/A
USB N/A
CD DVD YES
POWER SUPPLY 300 Watt or greater power supply
OPERATING SYSTEM MCE WINXP WINXP64 WINVISTA32 WINVISTA64
FORM FACTOR Low Profile Half-Height
DIMENSIONS [PRODUCT] : 11.75 X 9.5 X 3 inches [RETAIL BOX] : 11.75 X 9.5 X 3 inches [S BUILDER] : 11.75 X 7.25 X 2
WEIGHT [PRODUCT WEIGHT] : .60 LBS [PRODUCT WITH CONTENT WEIGHT] : 1.60 LBS
UPC RETAIL PACKAGE UPC : 757448006742
PACKAGE CONTENT
● DIAMOND STEALTH HD 4350 PCIE 512MB DDR2
VIDEO CARD
● DVI-TO-VGA ADAPTER
● COMPONENT HDTV ADAPTER
● QUICK START GUIDE
● INSTALL CD
PRODUCT WEBPAGE http://www.diamondmm.com/4350PE512.php
PRODUCT NOTES California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth
defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if
heating the solder.
Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.
ATI, Graphics by ATI, and Radeon are trademarks of ATI Technologies, Inc.
All other trademarks are property of their respective owners.
© 2009 Diamond Multimedia. All rights reserved. Diamond Multimedia 9650 DeSoto Ave
Chatsworth, CA 91311
Tel: (818) 534-1414 Fax: (818) 773-9619
http://www.diamondmm.com
