background image

DIAMOND MULTIMEDIA - SPECIFICATION SHEET
SKU 4870X2PE52G
BRAND HD 4800
May 4, 2009 - 4:13 pm

ENG APVD - LK 2008-07-03

MRKTG APVD - LL 2008-05-31

SKU

4870X2PE52G

PRODUCT

DIAMOND ATI Radeon™ HD 4870 X2 PCIE 2048MB GDDR5 Video Card

PRODUCT SHORT DESCRIPTION

INTERFACE

PCI Express x16

GPU

HD 4870 X2

CORE CLOCK

750 MHZ x 2

MEMORY CLOCK

900 MHz x 2

MEMORY CONFIGURATION

64Mx32

MEMORY TYPE

GDDR5

MEMORY BANDWIDTH

180.6 GB/sec

MEMORY SIZE

2048MB

MEMORY CONTROLLER INTERFACE

256-Bit x 2

PORTS

2 Dual-Link DVI,Video Out [S-Video, Composite, HDTV]

DUAL LINK DVI

Hydravision 4

PRODUCT DETAILED DESCRIPTION

ATI Avivo™ HD Video & Media
The ATI Radeon HD 4000 Series of GPUs allow you to experience the power of HD with graphics processing designed for
how you work and play. The Diamond Radeon™ HD 4870 X2 delivers outstanding performance at a great price. Advance
to the next generation of HD game performance and life-like realism thanks to DirectX® 10.1 capabilities and
plug-and-play ATI CrossFireX™ multi-GPU upgradeability. Watch the latest Blu-ray and HD-DVD videos in full 1080p HD
and upscale beyond - without placing huge demands on your CPU. Enjoy break-through efficiency with more processing
performance per watt and energy-saving features to help save you money.

PRODUCT FEATURES

GPU: Radeon™ HD4870 X2

Bus Type: PCI-Express

Core Clock: 750 MHZ x 2

Memory Size: 2048MB

Memory Configuration: 64Mx32 GDDR5

Memory Interface: 256-Bit X 2

Memory Speed: 900 MHz x 2

Two Dual Link DVI + HDTV-Out (HDMI support VIA Adapter)

SYSTEM REQUIREMENT

EXTERNAL POWER REQUIREMENT

6 pin & 8 pin Molex

CPU

Min. Intel 2.0 Celeron, Pentium Intel Duo, AMD 3800+ or
higher

CPU SPEED

2.0 Ghz or faster

MEMORY

1024MB

HARD DISK

480MB available hard disk space

SYSTEM BUS

PCI Express x16

SLOT

DOUBLE

CHASSIS

N/A

MONITOR

Digital flat-panel (DFP) displays or DVI-I Compatilbe or
digital CRT display or High-resolution VGA monitor

INTERNET ACCESS

N/A

USB

NO

CD DVD

YES

POWER SUPPLY

550 Watt or greater power supply with 75 Watt 6-pin and
8-pin PCI Express® power connector recommended.

OPERATING SYSTEM

MCE WINXP WINXP64 WINVISTA32 WINVISTA64

FORM FACTOR

Standard Profile Full-Height

DIMENSIONS

[PRODUCT] : 11.75 X 9.5 X 3 [RETAIL BOX] : 11.75 X 9.5 X 3 [S BUILDER] : 11.75 X 7.25 X 2

WEIGHT

[PRODUCT WEIGHT] : 2.75 LBS [PRODUCT WITH CONTENT WEIGHT] : 3.55 LBS

UPC

RETAIL PACKAGE UPC : 757448006490

PACKAGE CONTENT

DIAMOND ATI RADEON HD 4870X2 PCIE 2048MB
GDDR5 VIDEO CARD

QUICK START GUIDE

INSTALL CD

S-VIDEO CABLE

CROSSFIRE BRIDGE INTERCONNECT

COMPONENT HDTV ADAPTER

DVI-TO-VGA ADAPTER

DVI-TO-HDMI ADAPTER

PRODUCT WEBPAGE

http://www.diamondmm.com/4870X2PE52G.php

PRODUCT NOTES

California Health & Safety Notice : The solder used in this product contains lead, a chemical known to the State of California to cause birth
defects and other reproductive harm. Please wash hands after handling internal components and circuit boards and avoid inhalation of fumes if
heating the solder.

Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia.
ATI, Graphics by ATI, and Radeon are trademarks of ATI Technologies, Inc.
All other trademarks are property of their respective owners.
© 2009 Diamond Multimedia. All rights reserved.

Diamond Multimedia 9650 DeSoto Ave

Chatsworth, CA 91311

Tel: (818) 534-1414 Fax: (818) 773-9619

http://www.diamondmm.com
