SPECIFICATIONS
Model ZTR 5022
CHASSIS: 11 GA - rectangular tube
BODY: Two piece - made of high-density polyethylene. Front body contains access
panels for battery service and engine to mower deck belt removal. Rear body
tilts up to allow service on the entire drive system.
SEAT: Economically designed for operator comfort, contoured back rest and arm
rests. Seat is adjustable fore and aft.
MOWER DECK: 42" Deck: 13 GA Stamped Steel Construction - 42" Cut Width
50" Deck: 11 GA Fabricated Construction/Reinforcement Ribs - 50" Cut Width
60" Deck: 1 0 GA Stamped Steel Construction - 60" Cut Width
Cut height approximately 1 " to 4" via 7 position lift handle
BLADE DRIVE: Electric clutch
DRIVE SYSTEM: Each rear wheel is independently driven by a HydroGear BDU-10L Series 70
hydrostatic transmission. The hydrostatic transmissions, in turn, power a fully
enclosed HydroGear gearbox.
ENGINE: 22HP Kohler Command, 4-Cycle, V-Configuration, Overhead Valve, Air-Cooled,
Gasoline, Vertical Shaft, Aluminum Head, and Crankcase with Cast Iron Liners,
Full Pressure Lubrication/Full Flow Filter, Pulse-type Fuel Pump, Fixed Jet
Carburetor w/Smart-Choke, Electronic Ignition, In-Line Fuel Filter, Dual Element
Air Cleaner.
STARTING SYSTEM: Electric by key switch operation with safety interlocks on parking brake and
blade drive clutch.
TIRES: Front 11 X 4 X 5 ribbed tread
Rear 20 X 10 X 8 Multi Trac
RECOMMENDED Front 16-21 Ibs.
TIRE PRESSURE: Rear 8 -14 Ibs.
CAPACITIES: Fuel - 4.8 gallons total (dual tanks)
Hydrostat oil tank - 3 quart with in-line filter
Hydrostat oil recommendation, refer to page 35
Engine - 2 qts. SAE 10W30 (with filter)
DIMENSIONS: Width 51 "(42" Deck), 60"(50" Deck), 72"(60" Deck)
Height 45"
Length 72"
Weight 615 lbs.(42" Deck), 680 lbs.(50" Deck), 685 lbs.(60" Deck)
NOTE: Additional information provided in service instructions under the individual component
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
