PARTS LIST
This list contains replaceable parts used in your heater. When
ordering parts, follow the instructions listed under Replacement
Parts on page 30 of this manual.
KEY PART NUMBER
NO. VP10A VN10A DESCRIPTION QTY.
1 098304-01 098304-01 Screw, #10 x 3/8" 2
2 099467-07 099467-07 Front Panel Assembly 1
3 099318-03 099318-03 Grill Guard 1
4 101108-01 101108-01 Grill Guard Clip 2
5 099469-02 099469-02 Reflector Assembly 1
6 M15823-37 M15823-37 Screw Hex #8 x 1/4" 10
7 099059-03 503329 ODS/Pilot Assembly 1
7-1 098514-01 098514-01 Thermocouple 1
7-2 098594-01 098594-01 Ignitor Electrode 1
8 099884-02 099884-02 Burner Assembly 1
9 099056-01 099056-06 Injector 2
10 099390-02 099390-02 Tubing - Valve to plaque A 1
11 099387-05 099387-05 Pilot Tubing - Valve to pilot 1
12 099392-01 099392-01 Tubing - Valve to plaque B 1
13 099391-02 099391-02 Tubing - Regulator to valve 1
14 100432-01 100432-01 Control Valve 1
15 ** ** Cabinet Assembly 1
16 099415-18 099415-17 Gas Regulator 1
17 098303-02 098303-02 Screw, #6 x 5/16" 2
18 098508-01 098508-01 Valve Retainer Nut 1
19 099393-02 099393-02 Control Knob 1
20 M11084-26 M11084-26 Screw, #10 x 3/8" 2
21 099818-01 099818-01 Internal Tooth Washer 1
22 097159-04 097159-04 Piezo Ignitor 1
23 098271-03 098271-03 Ignitor Cable 1
PARTS AVAILABLE - NOT SHOWN
100642-02 100642-02 Assembly, Hardware 1
** Not a field replaceable part.
PARTS LIST
Models VP10A and VN10A
