ENGINE COMPARTMENT — 5.7L HEMI V-8

1 — Traction Power Inverter Module (TPIM) Coolant Bottle

8 — Washer Fluid Bottle

2 — Air Cleaner Filter

9 — Engine Coolant Bottle

3 — Engine Oil fill

10 — Fuses (Integrated Power Module)

4 — Engine Oil Dipstick

11 — Power Steering Fluid

5 — Brake Fluid Reservoir

12 — Remote Jump-Start Positive Battery Post

6 — Fuses (Power Distribution Center 2)

13 — Engine Coolant Pressure Cap

7 – Fuses (Power Distribution Center)
