Chrysler 2009 Aspen Hybrid User Manual

Page 106

background image

Cavity

Cartridge

Fuse/

Relay

Mini-

Fuse

Description

32

Micro-

Relay

Fuel Pump-2

33

Micro-

Relay

Stop Lamp Switch

34

Spare

Micro-
Relay

N/A

35

Micro-

Relay

Fuel Pump

36

Spare-

Micro-
Relay

N/A

37

Spare-

Micro-
Relay

N/A

38

20 Amp

Yellow

BPCM Fan

Cavity

Cartridge

Fuse/

Relay

Mini-

Fuse

Description

39

10 Amp

Red

BPCM Logic

40

20 Amp

Yellow

ASSY TRANS

41

10 Amp

Red

TPIM Pin 7/56

42

10 Amp

Red

TPIM Pin 6/56

43

10 Amp

Red

HVAC Pump

44

Mini-

Relay

Blower Motor

45

Mini-

Relay

ASD

104

MAINTAINING YOUR VEHICLE
