6
Faceplate Removal
Semi-Permanent
Faceplate Installation
Power On/Off
Mode
Auxiliary Input
Volume
Mute
Preset EQ Curves
Reset
Display
Set the Clock
12/24-hour Clock
General Operation
MXD662B OPERATION
Press RELEASE and pull away from the left side to remove.
To re-install, insert right side of faceplate first then push
left side to secure.
Remove trim ring and install supplied #1 x 7/32” Phillips
head screw through left side of mounting frame into faceplate.
Press or any other button (except eject) to turn the unit
on. Inserting a disc will turn the unit on automatically. Press
and hold to turn the unit off.
Press MODE to select between AM/FM, CD player, auxiliary
input and USB. Modes of operation are indicated in the
display.
Note: CD mode will not appear unless a CD is inserted.
Insert 3.5 mm plug to connect your portable audio device.
The steering wheel interface input located on the back of the
Adjust volume using rotary encoder (00-46).
Press MUTE to silence the audio. “MUTE” will flash in the
display. Press MUTE again to cancel.
Press EQ to enter EQ setup menu, then use the rotary
encoder to select between POP, JAZZ, CLASSIC, BEAT, ROCK
and FLAT (default) equalization curves. Any adjustment to
the Bass or Treble settings automatically cancels the current
EQ curve (if one is selected).
Press to RESET the unit upon initial installation or if
abnormal operation occurs. The reset button is located
behind the faceplate.
Press DISP to select between clock and different types of
information, such as radio frequency, CD track or MP3/USB
song information.
With the unit on, press and hold DISP until the clock begins
to flash, then release. Press TUNE
nn
to adjust the
hours and TUNE ll to adjust the minutes. Press DISP
momentarily to save the selected time.
The clock will display 12-hour AM/PM time in USA frequency
spacing mode (PM 10:00). In European frequency spacing
mode, the clock will display 24-hour time (22:00).
