PARTS LIST
MODELS VC42N, VVC42N, VC42P, VVC42P, CGCDV42NR AND
CGCDV42PR SERIES
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 37 of this manual.
REFRACTORY BRICK PANELS
VC42NB
VC42PB
CGCDV42NR
CGCDV42PR
VVC42NB
VVC42PB
VVC42NB-HA
VC42NH
VC42PH
VVC42NH
VVC42PH
DESCRIpTION
qTY
111299-02
111299-01 111302-02 111302-01 Left Refractory Brick Panel
1
111297-02
111297-01 111300-02 111300-01 Rear Refractory Brick Panel
1
111298-02
111298-01 111301-02 111301-01 Right Refractory Brick Panel
1
KEY
NO.
pART
NUMBER
DESCRIpTION
QTY.
1
**
Firebox Assembly
1
2
**
Face Weldment
1
3
108328-01 Door Assembly
1
108328-02 Door Assembly (V Models Only)
1
4
108331-01 Top Louver Assembly
1
5
108331-02 Bottom Louver Assembly
1
6
**
Fireplace Top
1
7
**
Fireplace Top Insulation
1
8
**
Fireplace Surround
1
9
109082-01 Heat Shield
1
10 116216-01 Log Set with Grate Assembly
1
11 116338-01 Right Burner Log
1
12 116339-01 Left Burner Log
1
13 See Below Left Refractory Brick Panel
1
14 See Below Rear Refractory Brick Panel
1
15 See Below Right Refractory Brick Panel
1
16 108455-01 Screen Rod
1
17 107840-01 Screen
2
18 11418
Push-On Nut
2
19 14123
Strain Relief
1
20 21171
Gas Knock-Out Cover
2
21 24353
Handy Box Assembly
1
22 24460
Gas Conduit Assembly
1
23 116211-01 Burner Assembly (Natural Gas) (See page 40)
1
116211-02 Burner Assembly (Propane/LP Gas) (See page 40)
1
116211-05 Burner Assembly for High Altitude Models (See page 40)
1
24 116375-01 Plenum
1
PARTS AVAILABLE - NOT SHOWN
25487
Lava Rock/Bag Assy
1
27253
Notice Label
1
55240
Vent Label
1
116388-01 Grate Finial
2
** Not a field replaceable part.
