Wyred 4 Sound DSDse User Manual
Page 19
_____________________________________________________________________
WYRED 4 SOUND DAC-v1.4
4235 Traffic Way
Atascadero, CA 93422
PH: 805-466-9973
FAX: 805-462-8962
©2014 WYRED 4 SOUND LLC
All rights reserved
pg. 17
D
D
A
A
C
C
-
-
2
2
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Typical Distortion
THD+N (20-20kHz A-weighted)
<0.006% THD+N
Frequency Response
(20-20kHz)
+/- 0.075db
S/N Ratio
> 115 db
Crosstalk
> 98 db
Noise (A-weighted)
< 7uV
Noise
< 10uV
Balanced Output Level
5.2V (14.2 db)
Unbalanced Output Level
2.6V (8.2 db)
Output Impedance
100Ω
Channel Tracking
< +/- 0.50 db
For lowering the output level with the Max setting, use the following numbers for the proper level:
(Make sure min is set to 0 for proper output level)
Output type / Output voltage / Volume setting
RCA / 2.6V / 70
RCA / 2V / 68
RCA / 1V / 62
XLR / 5.2V / 70
XLR / 4V / 68
XLR / 3V / 65
XLR / 2V / 62
XLR / 1V / 56
