Specifications – Wisdom Audio Insight Series L8i User Manual
Page 16
16
Specifications
All specifications are subject to change at any time, in order to improve the
product.
■
Frequency response
:
80Hz – 20 kHz ± 2dB relative to the target curve
■
Crossover frequency:
550 Hz
■
Nominal
Impedance
:
4Ω
■
Minimum
Impedance
:
2.5Ω
■
Sensitivity:
91 dB/2.83V/1m
■
Power handling, peak:
500w
■
Maximum SPL:
118 dB @ 1m
■
Dimensions:
see appropriate Dimensions drawings on next page
■
Recommended Enclosure Volume:
2.63 cubic feet (74.6 litres) or more
■
Minimum Enclosure Volume:
1.47 cubic feet (41.63 litres)
■
Maximum Wall Thickness: 1
1
⁄
4
" (3.175cm)
■
Shipping weight, each
:
xx lbs. (xx kg)
For more information, see your Wisdom Audio dealer, or contact:
Wisdom Audio
1572 College Parkway, Suite 164
Carson City, NV 89706
www.wisdomaudio.com
[email protected]
Ph: 775.887.8850
Fax: 775.887.8820
