Wisdom Audio Sage Series L75 - Manual (Page 25)

25
Specifications
All specifications are subject to change at any time, in order to improve the
product.
■ Frequency response : 40Hz – 20 kHz ± 2dB relative to the target curve
■ Impedance, planar section : 4.5 ohms resistive
■ Impedance, woofer section : 4 ohms nominal, 2.5 ohms minimum
■ Sensitivity, planar section: 95 dB/1w/1m
■ Power handling, peak: >1000w
■ Dimensions see appropriate Dimensions drawings on next several pages
■ Shipping weight, each L75 tower : 79 lbs. (36 kg)
■ Shipping weight, a pair of L75 bases : 30 lbs. (14 kg)
■ Shipping weight, each L75m : 69 lbs. (31 kg)
■ Shipping weight, each L75i : 65 lbs. (29 kg)
For more information, see your Wisdom Audio dealer, or contact:
Wisdom Audio
1572 College Parkway, Suite 164
Carson City, NV 89706
www.wisdomaudio.com
[email protected]
Ph: 775.887.8850
Fax: 775.887.8820
