Wisdom Audio Sage Series L150 - Manual (Page 22)

22
Specifications
All specifications are subject to change at any time, in order to improve the
product.
■ Frequency response : 20Hz – 20 kHz ± 2dB relative to the target curve
■ Impedance, planar section : 3 ohms resistive
■ Impedance, woofer section : 8 ohms nominal, 6.5 ohms minimum
■ Sensitivity, planar section: 97 dB/1w/1m
■ Power handling, peak: >1000w
■ Dimensions see appropriate Dimensions drawings
■ Shipping weight, bass section : 90 lbs. (41 kg)
■ Shipping weight, planar section : 53 lbs. (24 kg)
For more information, see your Wisdom Audio dealer, or contact:
Wisdom Audio
1572 College Parkway, Suite 164
Carson City, NV 89706
www.wisdomaudio.com
[email protected]
Ph: 775.887.8850
Fax: 775.887.8820
