WPB Series
INSTALLATION
Multiple mounting points are available on the wall plate for strong and secure mounting. Once
a suitable location is found for the mounting of the bracket safely secure the wall plate to the
wall, ensuring that it is level and mounted properly. Ensure that there is adequate support
for the weight of the speaker and bracket. Consider the construction and materials used in
the wall, and be sure to center the mounting points squarely in wall studs or supports with
adequate screw lengths.
Once the wall plate is securely mounted the arm mechanism should be attached using the
provided nut and bolt.
The tilt mechanism includes a mounting plate for attaching to the bottom of the speaker. The
tilt mechanism can be mounted directly on the arm with the provided hardware. Alternatively
the tilt mechanism can be mounted to the bottom of the speaker prior to attaching it to the
arm. Adjust the tilt to the desired angle and secure with the provided nuts and bolts, ensure
that all nuts and bolts are tightened sufficiently to hold the desired speaker in position.
WHARFEDALE PRO LIMITED WARRANTY
The Wharfedale Pro WPB Series Wall Brackets are warranted of manufacturing or
material defects for a period of one year from the original date of purchase. In the event of
malfunction, contact your authorized Wharfedale Pro dealer or distributor for information.
* Be aware that warranty details may differ from country to country. Contact your dealers or
distributor for information. These terms do not infringe your statutory rights.
2
