Volant Escalade - Manual (Page 4)

Closed Box Air Intake System
07-08 GM Truck/SUV 4.8/5.3L/6.0/6.2L
PN 15253/152536
7/29//2014
INS15253 Volant Performance · 140 Blaze Industrial Pkwy · Berea, OH 44017 · P: (909) 481.3888 · F: (440) 891‐1868
4
E-Mail: [email protected] www.volant.com
22. Slide the Volant duct into the hump hose and onto the throttle body . (Fig V)
23. Tighten the duct to the hump hose with a 5/16 socket or nut driver only. (Fig W)
24. Tighten the Volant duct to the throttle body with a 5/16 socket or nut driver only. (Fig X)
25. Press the 3/8 breather hose onto the Volant air duct port. (Fig Y)
26. Remove the protective film on the lid and line it up with the air box. (Fig Z)
27. Tighten the lid in place using the supplied truss head screws and rubber washers. (Fig AA)
28. Reinstall the factory engine cover. (Fig BB)
29. Place the supplied CARB EO label near the system, this label will be needed to pass a visual smog test. (Fig CC)
30. The install is complete, you can now reinstall the negative battery cable, Check all connections before starting
the vehicle and after 150 and 350 miles of normal driving. (Fig DD)
INSTALLATION PHOTOS ON NEXT PAGE
