Part No. 4GC218-090SQ
PARTS LIST
Part Number
Description
Quantity
4GC112-010
AIR INTAKE ASSEMBLY
1
4GB012-010
Air Filter Cover
1
4GC012-012
Air Inlet Tube
1
4FA012-012
90
°
Intake Elbow
1
7P375-017
3/8” NPT x 1/2” Straight Hose Barb
1
7S350-200
3-1/2” x 2” Sleeve
1
7R002-056
#56 Hose Clamps
2
7R002-052
#52 Hose Clamps
4
7E010-046
#8 x 3/4” Sheet Metal Screws
2
7U035-000
3-1/2” x 10” Flex Hose
1
8H040-040
Air Filter
1
7U030-005
1/2” x 5” Oil Drain Hose
1
7U035-000
3-1/2” x 12” Flex Hose
1
7R001-008
#8 Stainless Hose Clamps
2
4GC112-020
AIR DISCHARGE ASSEMBLY
1
4GB040-060
Air/plenum Gasket
1
4GC012-020
Steel Discharge Tube
1
4GC050-011
Intake Plenum
1
7A312-050
5/16-18 x 1/2” Bolts
2
7J312-000
5/16” SAE Flat Washers
2
7P125-025
1/8” NPT to 5/32” Barb
1
7R002-044
#44 Hose Clamps
4
7S275-200
2-3/4” x 2” Sleeves
2
7P750-102
3/4" NPT x 1" 90
°
Hose Fitting
1
7P750-100
3/4" NPT x 1" Straight Hose Fitting
1
7R002-016
#16 Hose Clamps
4
8D001-001
Bypass Valve
1
7U030-046
5/32" x 24" Vacuum Line
1
7P156-082
5/32" Tee
1
7U034-016
1" x 3" Heater Hose
1
7U034-016
1" x 8.5" Heater hose
1
8H040-075
1" Filter
1
4FA111-032
BELT TENSIONER ASSEMBLY
1
7J012-092
12mm Flat Washers
3
4FA011-032
Belt Tensioner Plate
1
7C012-050
12mm x 1.75 x 50mm Bolt
1
4FA016-150
Smooth Pulley Tensioner
1
2A017-010
Idler Pulley Spacer
1
7C012-020
12mm x 1.75 x 20mm Bolts
2
7C012-022
12mm x 1.75 x 22mm Thin Head Bolt
1
7G010-175
12mm x 1.75 Nut
1
4GC160-010
FUEL CONTROL ASSEMBLY
1
4GC152-011
Spacer Block Assembly
1
4GB112-022
Plenum Rod Assembly
1
4GB101-002
FUEL PUMP ASSEMBLY
1
8F001-002
155 Inline Fuel Pump
1
7R003-024
1-1/2” Adel Clamp
1
5W001-011
16-14 GA Eyelet
1
5W001-001
Wire Tap
1
5W001-010
16-14 GA insulated Female Slides
6
5W001-014
Fuse Holder
1
5W001-015
Blade type 20A Fuse
1
5W001-017
Large Ring Terminal
1
8F101-200
T-Rex
®
Wiring Assembly
1
5W001-002
Fuse Tap
1
7R001-008
#8 Hose Clamps
2
7P625-001
Fuel Adapter Fitting
1
7U030-050
12mm x 8” PCV Hose
1
7J010-001
#10 Flat Washers
4
7F010-032
10-32 Nylock Nut
2
7U100-055
6” Nylon Tie Wraps
4
7C011-075
10/32” x 3/4” Cap Screw
1
Part Number
Description
Quantity
2E228-090
V-2SQ SUPERCHARGER ASSEMBLY
1
4GC111-021
MOUNTING BRACKET ASSEMBLY
1
4GC010-034
Mounting Plate
1
4GC010-043
Attachment Plate
1
4GC010-054
Stiffener plate
1
4GC011-021
Mounting Bracket
1
4GC017-011
.125 Mounting Plate Spacer
1
7A375-550
3/8-16 x 5-1/2” Bolt
1
7F375-016
3/8-16 Nuts
3
7K375-040
3/8” AN960 Flat Washers
5
7J375-044
3/8” SAE Washers
8
7A375-100
3/8-16 x 1” Bolts
10
7C010-025
M10-1.5 x 25mm Bolts
2
7A312-100
5/16-18 x 1” Bolts
4
7J312-000
5/16” SAE Flat Washers
8
4GC010-010
Mounting Bracket Support
1
7A375-208
3/8-16 x 2” Bolt
1
7A375-276
3/8-16 x 2-3/4” Bolt
1
7F312-018
5/16-18 Nuts
4
4GB017-011
1” Throttle Spacer
1
7A375-124
3/8-16 x 1-1/4” Bolts
2
4GC116-010
CRANK PULLEY ASSEMBLY
1
4GB016-011
Crank Pulley
1
4GC017-041
Crank Pulley Spacer
1
7B375-400
3/8-24 x 4” Bolts
3
7J375-044
3/8” SAE Washers
3
7L375-075
3/8" Lock Washers
3
4GC017-010
Spacer Fan
1
7C080-055
M8 1.25 x 55 Studs
4
2A046-598
Belt
1
7B500-400
1/2-20 x 4” Bolt
1
4GC130-026
OIL FEED LINE ASSEMBLY
1
7U030-026
1/4” x 16" Oil Feed hose
1
7P525-067
.500 Crimp Ferrules
2
7P250-066
#4 Swivel x 1/4” Hose Barb Fittings
2
7P250-036
#4 Flare to 1/4” NPT
1
7P125-026
1/8” NPT 90
°
Fitting
1
7P250-034
1/4” NPT x 1/4” NPT Straight Tee
1
7U100-055
6” Nylon Tie Wraps
3
4GC130-036
OIL DRAIN ASSEMBLY
1
7R001-008
#8 Stainless Hose Clamps
2
7U030-036
1/2” x 36” Oil Drain Hose
1
7P375-033
3/8” NPT x 3/8” NPT Street Elbow
1
7P375-017
3/8” NPT x 1/2” Straight Hose Barb
1
7U100-055
6” Nylon Tie Wraps
4
5A001-004
FUEL INJECTION COMPUTER
1
®
ENGINEERING, LLC
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages
