PARTS LIST
MODELS CF26PT AND CF26NT
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 26 of this manual.
KEY
NO.
PART NO. DESCRIPTION QTY.
1 102633-02 Outer Casing Top 1
2 102624-02 Outer Casing 1
3 099230-02 Shoulder Screw 12
4 105631-01CK Assy. Hood Weldment 1
5 105258-01CK Vertical Front, Left and Right Sides 2
6 105259-01 Firebox Top 1
7 ** Firebox Wrapper 1
8 ** Bayfront Base 1
9 105421-01 Heat Deflector 1
10 105409-01 Fan Control Shield 1
11-1 105401-01 Screen Rod 1
11-2 105440-01 Screen Assembly 1
12 101386-02 Hinge 2
13 ** Rivets 8
14 105262-01CK Louvered Door 1
15 ** Firebox Floor 1
16 098304-01 Screw, #10 x 3/8" 21
17 105256-01CK Bayfront Bottom Panel 1
18 M11084-26 Hex Head Screws #10 x .38 26
19 105513-01CK Cover, Screen Rod 1
20-1 105525-01 Fiber Brick, Left 1
20-2 105524-01 Fiber Brick, Rear 1
20-3 105526-01 Fiber Brick, Right 1
21 105987-01 Brick Liner Retainer 2
PARTS AVAILABLE — NOT SHOWN
101054-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
103470-01 Hardware Package 1
** Not a field replaceable part.
PARTS LIST
Models CF26PT and CF26NT
