ELF™
4
4.5 STATUS INDICATORS
4.5.1 LED Status
The Elf provides three different LEDs signaling the mobile computer status.
LED STATUS
Good Read
(right side) Red Scanning LED is ON from the
time the user hits the scan button
(Trigger) until the bar code is
decoded (laser models)
Time-out (imager models)
Green Scanning LED is ON, showing a
good decode.
Charging Status
(left side) Green It is constant once the charging
process has been completed (full
charge).
Red It is constant while charging.
Red blinking charge fault
Keyboard Status
(center)
Off
Keyboard in primary
Yellow solid
Yellow alternate key mode
Blue solid
Blue alternate key mode
Pink CapsLock available for use by the
application, cause and duration
42
