Specifications
AM-5AC22-45
Dimensions 750 x 215 x 94 mm
(29.53 x 8.47x 3.70")
Weight (Mount Included) 6 kg
(13.23 lbs)
Frequency 5.15 - 5.85 GHz
Gain 22 dBi
HPOL Beamwidth 45° (6 dB)
VPOL Beamwidth 45° (6 dB)
Elevation Beamwidth 4°
Electrical Downtilt 2°
Max. VSWR 1.5:1
Wind Survivability 200 km/h
(125 mph)
Wind Loading 347 N @ 200 km/h
(78 lbf @ 125 mph)
Polarization Dual Linear
Cross-Pol Isolation 30 dB Min.
ETSI Specification EN 302 326 DN2
Mounting Universal Pole Mount, Rocket Mount Bracket,
and Weatherproof RF Cables Included
*640-00125-01*
640-00125-01
