Frequency Configuration
FDD will be most useful in situations that have plenty of
spectrum available and will show the greatest benefit on
shorter-range links. For optimal performance, you should plan
out channel pairs that have maximum frequency separation.
Since the AF5 uses sophisticated data processing algorithms
and a special antenna structure to eliminate the need for a
pre-configured duplexing filter, you should space the 2 duplex
channels at either end of the spectrum near the band edges
for maximum-range applications.
Generally speaking, you can configure shorter-range links
for less channel separation between uplink and downlink.
You should also use the narrowest channel bandwidth that
supports the intended link capacity. This conserves valuable
frequency resources and also maximizes link budgets.
Ubiquiti Networks
™ is currently developing a configuration tool,
the airFiber5 Link Calculator*, that will guide you on how to
best minimize bandwidth and power/interference based on
the specific requirements of your installation.
* The airFiber5 Link Calculator will be available as a new tool in an upcoming firmware update. Check community.ubnt.com/airfiber for firmware announcements.
50.0 miles Range Margin Min Power Max Power 6.0 dB 15 dBm 47 dBm
5800 MHz
100 Mbps
5800 MHz
100 Mbps
5900 MHz
10 Mbps
Channel Bandwidth 40 MHz
Transmit Power 46 dBm
Aggregate Capacity 204.80 Mbps
Receive Power -77.83 dBm
Modulation Rate
Frequency
Capacity
Bandwidth
4x <16QAM>
Downlink Bandwidth 40 MHz
Transmit Power 46 dBm
Downlink Capacity 204.80 Mbps
Receive Power -77.83 dBm
Modulation Rate
Frequency
Capacity
Bandwidth
4x <16QAM>
Uplink Bandwidth 10 MHz
Transmit Power 36 dBm
Uplink Capacity 23.04 Mbps
Receive Power -87.98 dBm
Modulation Rate
Frequency
Capacity
Bandwidth
2x
10 MHz
20 MHz
30 MHz
40 MHz
50 MHz
10 MHz
20 MHz
30 MHz
40 MHz
50 MHz
10 MHz
20 MHz
30 MHz
40 MHz
50 MHz
TDD FDD Transmit FDD Receive
airFiber5 Link Calculator
Calculate
Calculate
1.0 miles Range Margin Min Power Max Power 6.0 dB 15 dBm 47 dBm
5800 MHz
250 Mbps
5800 MHz
100 Mbps
5900 MHz
500 Mbps
Channel Bandwidth 40 MHz
Transmit Power 23 dBm
Aggregate Capacity 307.20 Mbps
Receive Power -66.85 dBm
Modulation Rate
Frequency
Capacity
Bandwidth
6x <64QAM>
Downlink Bandwidth 20 MHz
Transmit Power 20 dBm
Downlink Capacity 149.76 Mbps
Receive Power -69.85 dBm
Modulation Rate
Frequency
Capacity
Bandwidth
6x <64QAM>
Uplink Bandwidth 50 MHz
Transmit Power 31 dBm
Uplink Capacity 512.00 Mbps
Receive Power -59.00 dBm
Modulation Rate
Frequency
Capacity
Bandwidth
8x <256QAM>
10 MHz
20 MHz
30 MHz
40 MHz
50 MHz
10 MHz
20 MHz
30 MHz
40 MHz
50 MHz
10 MHz
20 MHz
30 MHz
40 MHz
50 MHz
TDD FDD Transmit FDD Receive
airFiber5 Link Calculator
Examples of airFiber5 Link Calculator (available soon)
