TrakPower MS Series Sensored Brushless Motors - Manual

Specifi cations
PART NUMBER
TURN
TKPC5015
6.5T 8.5T 10.5T
INPUT VOLTAGE 2–3S LiPo
MOUNT HOLE DEPTH 4mm
SHAFT DIAMETER 3.175mm
SHAFT LENGTH 15mm
DIMENSIONS 35.9 x 52.4mm
WEIGHT 175g 167g
13.5T 17.5T 21.5T
TKPC5025 TKPC5035 TKPC5040 TKPC5045 TKPC5050
Warnings
Please read thoroughly before installation and operation.
• DO NOT apply an input voltage that exceeds
the maximum specifi cations of each motor.
• DO NOT allow the input connectors to touch
each other while power is applied to the
motor. Make sure all input connections are
insulated electrically.
• DO NOT attempt to modify this motor.
• DO NOT allow water or moisture to enter the
motor, as it can cause permanent damage
to the motor and possibly short out the
attached ESC.
• Allow the motor to cool down after each run.
• DO NOT attempt to use a damaged motor
(having mechanical or electrical defects).
BRUSHLESS MOTOR
™
Thank you for making TrakPower your
choice in brushless power systems.
TrakPower brushless motors are built
with the fi nest raw materials available
to provide the best and most effi cient
power possible. CNC machined aluminum
ribbed cans and cooling vents provide
excellent heat dissipation, keeping the
operating temperatures low for better
performance and longevity. The high
temperature resistant rotor is coated
to prevent breakdown of the magnet
strength. The TrakPower MS series
motors are a perfect match for the
TrakPower MS-1 Brushless Racing ESC.
