Thermionic Culture THE NIGHTINGALE 2 Dual mic. Amp/equaliser+ compressor - Manual (Page 17)

©Thermionic Culture Ltd August 2014 16
8 Specification
Preamps
A & B
Compressor
Input Impedance
Mic Lo
Mic Hi
Line 600Ω
1200Ω
10kΩ
N/A
N/A
10kΩ
Output Impedance <400Ω <600
MOL (into 10kΩ) +26dBu +26dBu
Distortion (1kHz) 0.1% 0.02% *
Frequency Response
+0/-1 dB
<10-35kHz 13-80kHz
Total Noise (unweighted
30kHz filter) below MOL
103dB 105dB
Max Gain 34dB 28dB
Phantom Power +48V N/A
* Increases with compression to a typical figure of 0.2% with
6dB compression.
The Nightingale can be set to operate from either 230V or
115V 50/60 Hz AC. The appropriate mains input voltage can
be selected on the red switch located next to the mains inlet.
Note: Mains fuses must be replaced in accordance with the
following table.
Mains Voltage Fuse Rating
230V T315mA
115V T630mA
