TFC Group Trealux 710 - Manual (Page 7)

7
GB
3. Technical Data
Connection see unit imprint
Switching capacity AC
– incandescent lamp load cos
ϕ = 1 1200 W
Switching contact N/O contact
Ambient temperature –10° C … +55° C
Protection class/Protection type II/IP 20
Adjustment range 0,5 … 99,5 minutes
Dimming time 0 … 30 seconds
Glow lamp load max. 50 x 1 mA
ON period 100% ON duration
Hand switch yes
Resettable immediately
Connection type captive +/– screws
Switching type 3/4 wire connection
Diagnosis function yes
Caretaker function = 1 hour press for approx. 3 sec.
Prewarning yes
