TFC Group Talento 371 Mini Plus - Manual (Page 11)

23
GB
Operating mode
4
14:26
FIX
Res Menu ok
Esc
– +
Info
Press 1 x = FIX ON = continuous ON
Press 2 x = FIX OFF = continuous OFF
Press 3 x = return to Auto mode
FIX ON:
FIX
FIX OFF: FIX
AUTO: (no display) programmed switching times
Technical data
Dimensions H x W x D 45 x 17,5 x 60 mm
Weight g (approx.)
90
Supply voltage see imprint on device
Power consumption 5 VA
Switching capacity
- ohmic load
(VDE, IEC)
16 A/250 VAC
- inductive load
cos ϕ 0.6
8 A/250 VAC
- Incandescent
lamp load
1,000 W
Switching output potential-free
Switch contacts 1 changeover contact
Ambient temperature -13°F to 131°F (-25°C
to +55°C)
Protection class II
Accuracy typ. ±2.5 s/day
at 68°F (20°C)
Reserve power 3 years from factory
at +68°F (20°C)
Shortest switching time 1 min.
Memory spaces
50
Block formation of
day of the week
fixed/free selection
Switching status
display
yes
Sealable yes
