MS-20 C
MS-22 C
Part No.
Notes
Description
Specifications
1
1
1
374 101 000
SHAFT PIPE COMPLETE
1
2
1
374 150 040
SHAFT
1
3
1
374 300 400
GEAR CASE ASS'Y
INC. 4,5,6,7,8-16
1
4
1
367 300 300
CUTTER SHAFT SET
1
5
1
381 250 030
BALL BEARING
#609ZZ
1
6
1
367 006 999
BALL BEARING
626ZZ
1
7
1
367 010 993
BALL BEARING
6000DDU
1
8
1
381 850 010
RECEIVE WASHER
1
9
1
381 300 401
WASHER
1
10
1
381 150 800
OUTER SNAP RING
1
11
1
381 142 400
INNER SNAP RING
1
12
1
381 142 600
INNER SNAP RING
1
13
1
367 301 101
OIL BOLT
M6X9
1
14
1
381 300 402
NUT
M8
1
15
1
367 905 989
SOCKET HEAD BOLT
M5X25
1
16
1
381 150 140
GASKET
1
17
1
367 905 990
SOCKET HEAD BOLT
M5X12
1
18
1
381 700 200
HANGER ASS'Y
INC. 19
1
19
1
374 905 985
SOCKET HEAD BOLT
M5X14
1
91
1
381 005 994
TAPPING SCREW
1
92
1
374 500 700
CONTROL LEVER ASS'Y
INC. 93,94
1
93
2
374 906 988
SOCKET HEAD BOLT
M6X20
1
94
2
374 501 114
NUT
1
95
1
374 450 000
HANDLE (LOOP TYPE)
1
96
4
367 905 986
SOCKET HEAD BOLT
M5X33
1
97
4
381 270 500
NUT
M5
1
99
2
374 330 565
SCREW ASS'Y
1
100
1
374 300 403
AIR CLEANER COVER
1
101
1
374 300 401
AIR FILTER
1
102
1
374 300 402
AIR CLEANER HOUSING
1
103
1
374 600 500
CARBURETOR
INC. 105,106,108-120
1
104
1
374 606 100
O RING
1
105
1
381 601 804
SWIVEL
1
106
2
388 600 803
PAN HEAD SCREW
1
108
1
381 600 512
RING
1
109
1
381 600 101
O RING
1
110
1
374 600 202
JET
1
111
1
381 600 103
PUMP GASKET
1
112
1
381 600 104
PUMP DIAPHRAGM
1
113
1
381 600 401
INLET SCREEN
1
114
1
374 604 613
PUMP BODY ASS'Y
INC. 113
1
115
1
381 604 604
METERING DIAPHRAGM GASKET
1
116
2
381 600 525
METERING DIAPHRAGM ASS'Y
1
118
1
381 600 115
PRIMER PUMP
1
120
4
381 604 601
PUMP COVER SCREW
1
404
1
381 800 800
PROTECTOR ASS'Y
INC. PROTECTOR CLAMP & BOLT
MS-20 C
