6
SPECIFICATIONS
Instrument General
Operating Temperature Range -10˚C to +50˚C
Operating Humidity
Less than 95% non-condensing
Battery 6 each 1.5Volty “AAA” Alkaline batteries
Battery Life > 30 Hours Continuous Use
Display Backlit Dual LCD with function annunciators
Dimensions 74mm x 144mm x 29mm
Weight 150g
Casing Rubber Boot as Standard
Switch Off Auto Power Off after 10 minutes
Sensors
Temperature Measurement
-20˚C to +80˚C (-5˚F to 175˚F)
Temperature Accuracy ±1% of reading ±0.5°C
±1% of reading ±1.0°F
Velocity Measurement
0.2 to 20 m/s
Velocity Accuracy ±5% of reading ±3 digits
Units of Measure m/s, km/s, ft/min, knots, mile/h
RS232 Output
Holding down "RCL" button will display "MAX, "MIN", "AVG". And then
"RS-232" at the top right of the screen.
This function prints the reading currently being measured in ASCII code.
RS232 cable is needed in order to view the readings on your computer.
3
1. Introduction
Thank you for purchasing TPI brand products. The TPI 565 Hot Wire Air Velocity
Meter is a state of the art, easy to use instrument designed to provide temperature
and air velocity readings. The instrument is ruggedly constructed and comes with
a 3 Year Guarantee.
This manual will guide you through the functions of the TPI 565 which will give
you many years of reliable service.
Your TPI 565 Hot Wire Air Velocity Meter comes complete with the following items
as standard:
TPI 565 Instrument
Rubber Boot
Soft Carrying Case
Batteries
Instruction Manual
Your TPI 565 Hot Wire Air Velocity Meter has the following options available:
Serial Computer Interface RS232
