Audio 1-in, Audio 2 l/r (rca jack), Audio out – Dukane 8065 User Manual
Page 103: Control, Model 8755d-rj only, Ø3.5 stereo mini jack), i j, Usb b type jack m
101
Connection to the ports
Y
R
L
AUDIO IN2
AUDIO OUT
CONTROL
RGB IN1
RGB IN2
USB
RGB OUT
AUDIO IN1
VIDEO
S-VIDEO
C
B
/
P
B
C
R
/
P
R
K
H
M
H
AUDIO 1-IN (
Ø3.5 stereo mini jack),
I J
AUDIO 2 L/R (RCA jack)
• 200mVrms(max.) 35kΩ termination
K
AUDIO OUT (
Ø3.5 stereo mini jack)
• 200mVrms(max.) 1kΩ output impedance
L
USB
USB B type jack
M
CONTROL
D-sub 9pin plug
• About the details of RS-232C communication, please refer to the following page.
Pin
Signal
Pin
Signal
Pin
Signal
1 (No connection)
4 (No connection)
7 RTS
2 RD
5 Ground
8 CTS
3 TD
6 (No connection)
9 (No connection)
9
8
7
6
5
4
3
2
1
2
1
3
4
L
I
J
K
Pin
Signal
1 +5V
2 - Data
3 + Data
4 Ground
LAN
LINK
ACT
N
N
LAN Port
Used for Ethernet input/output.
This port is used when utilizing network functions.
RJ-45 Jack,
Model 8755D-RJ Only!
