Product Introduction
The Summit Audio TPA-200B uses vacuum tube and solid state
technologies to produce the warm sound associated with tubes with the
reliability provided by solid state devices. The TPA-200B is designed to
work in a number of different applications with the different types of inputs:
a microphone input, line level input, and a front panel Hi-Z input. Input
connections are made by using three pin balanced XLR jacks, balanced TRS
¼” jacks, and the front panel unbalanced ¼” jack.
Features include:
Easy operation
Controllable sound, continuously variable from “clean” to “overdrive”
Jensen input transformers
Line level balanced input
Mic level balanced input
Phantom power
Front panel Hi-Z input
990 balanced output stage
Overload and overdrive indicators
Polarity reversal
-15dB and –25dB pads
Hand crafted in the USA
Having found this manual, carefully unpack the TPA-200B and it’s power cord. Save the
carton and packing material should it be needed for future shipping. Before powering the
unit, read this manual. Please observe the cautions for HIGH VOLTAGE. Proceed by
doing the following:
1. Set the line voltage switch to the proper position
2. Determine the proper fuse size by referring to the specifications
3.
Check for pilot illumination when powered up.
