D89-0000-0231 Rev. A00

StorCase Technology, Inc.

SCSI Ultra320 Cable Kits

Figure 3: Installation Overview

(S90A114 shown)

0570E

SCSI Ultra320

Board

Power

Cable

Mounting

Screws

(2 plcs)

Total External SCSI Cable

Length From Host to Last

Chassis Connector Should

Not Exceed 12 Meters (39 ft)

NOTE: Disable Onboard Termination

on All Drives

Internal SCSI

I/O Cable

External Ultra320

(LVD/S.E.) Terminator

(Not Included)

9 Drives

(Not Included)

6 Drives

(Not Included)
