Ultra SCSI Cable Kit
INSTALLATION
1. Disconnect all power and remove cables from the Data Silo chassis.
2. Open the Data Silo chassis to gain access to the internal cables and rear
panel I/O connectors. Refer to the Data Silo User's Guide if necessary for
information on this procedure.
3. Remove existing internal SCSI ribbon cable if installed.
4. Verify that ALL devices within the Data Silo chassis have termination disabled.
5. Remove existing chassis rear panel connector(s) if necessary.
6. Unfasten the fan power cable bracket from inside the Data Silo panel by
removing bracket screw. Remove bracket from fan power cable assembly
and discard (see Figure 1).
NOTE:
The fan power cable bracket must be removed before the
DCULTRA-KIT can be installed.
7. Attach one end of the power cable to the Ultra SCSI board, attach the other end
to the Data Silo power strip. The position of existing device power cables may
need to be adjusted to accommodate the Ultra SCSI power cable.
8. Attach the Ultra SCSI repeater board to the Data Silo rear panel with the two
(2) provided screws, component-side facing away from the Data Silo panel
(see Figure 2).
9. Connect the internal SCSI ribbon cable to the Ultra SCSI board and installed
devices.
10.Reinstall the Data Silo covers and cables removed earlier.
11.If using a SCSI daisy-chain with multiple Data Silo chassis, verify that the
external SCSI cable meets the SCSI 3 (40 MBytes/sec) Specification and that
the cable does not exceed 3 meters (9.84 ft) in length.
NOTE:
Ultra2 (LVD) devices can be installed with the
DCULTRA-KIT, but will only operate in Single-Ended
mode (maximum transfer rate of 40 MBytes/sec).
