Star Headlight & Lantern TDDL15 Series High Intensity User Manual

Page 2

-i-

Please Note: These instructions are provided as a general guideline only. Specific
mounting and/or wiring, may be necessary and are the sole responsibility of the
installer. Star Headlight & Lantern Co., Inc. assumes no responsibility for the
integrity of the installation for this or any of its products.

NOTICE

Due to continuous product improvements, we must reserve the right to change any
specifications and information, contained in this manual at any time without notice.
Star Headlight & Lantern Co., Inc. makes no warranty of any kind with regard to this
manual, including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Star Headlight & Lantern Co., Inc. shall not be liable
for errors contained herein or for incidental or consequential damages in connection
with the furnishing, performance, or use of this manual.

Table of Contents

Warnings, Dimensions, and General Notes

1-2

MOUNTING INSTRUCTIONS

3-7

Standard Mounting

3-4

TDDL15-47CV Mounting

TDDL15-47TA Mounting

6-7

ELECTRICAL CONNECTIONS

8-9

JUMPER SETTINGS

OPERATION

11-13

TROUBLESHOOTING

WARRANTY

SERVICE
