35 106517
OWNER’S MANUAL
PARTS LIST
DIRECT-VENT FIREPLACE
BHDV37NC
BHDV41NC
This list contains replaceable parts used in your fireplace. When ordering parts, follow the
instructions listed under Replacement Parts on page 33 of this manual.
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 104547-02 Top Outer Casing - 37" 1
104547-03 Top Outer Casing - 41" 1
2 104474-02 Outer Casing - 37" 1
104474-03 Outer Casing - 41" 1
3 104548-02 Bottom Outer Casing - 37" 1
104548-01 Bottom Outer Casing - 41" 1
4 104479-08BR Firebox Assembly - 37" 1
104479-07BR Firebox Assembly - 41" 1
5 M11084-26 Screw, Hex 52
6 M11084-46 Screw, Hex 13
7 102455-04 Louver, Extruded - 37" 2
102455-03 Louver, Extruded - 41" 2
8 104443-01 Firebox Support, Right 1
9 104486-01 Firebox Support, Left 1
10 104482-01 Switch Bracket 1
11 104483-01 Floor Mounting Bracket 2
12 104491-01 Relief Cover 1
13 104518-01 Relief Cover Gasket 1
14 104527-01 Relief Spring 2
15 104528-01 Relief Washer 2
16 104537-01 Valve Bracket 1
17 104496-01 SIT Valve, Natural 1
18 104497-01 SIT Pilot, Natural 1
19 104498-01 Thermocouple 1
20 104499-01 Thermopile 1
21 104500-01 Ignitor 1
22 104501-01 Ignitor Bracket 1
23 104502-01 Ignitor Screw 1
24 104503-01 Ignitor Wire 1
25 104504-01 Burner 1
26 104506-01 Orifice - 37" 1
104506-03 Orifice - 41" 1
27 104507-01 Brass Elbow 1
28 104508-01 Brass Fitting 2
29 104509-01 Aluminum Tubing Assy 1
30 104510-01 Pilot Tubing Assy 1
31 101628-04 Flexible Connector 1
32 105325-01 Burner Baffle 1
33 104515-02 Wire for Wall Switch - 15' 1
34 107165-01 Log Set - 37" 1
107164-01 Log Set - 41" 1
34-1 107344-02 Rear Log - 37" 1
107344-01 Rear Log - 41" 1
34-2 107345-02 Front Log - 37" 1
107345-01 Front Log - 41" 1
34-3 107346-01 Crossover Log - 37" & 41" 1
34-4 107347-02 Log Piece - 37" 1
107347-01 Log Piece - 41" 1
34-5 107348-01 Top Small Log - 37" & 41" 1
35 M10908-2 Screw 6
36 M12461-65 Screw 3
37 H5C4-20B Bolt 2
38 NTC-4C Locknut 2
39 M12461-26 Screw 4
40 104555-02CJ Grate Assembly - 37" 1
104555-01CJ Grate Assembly - 41" 1
41 105775-04 Glass Door Assy - 37" 1
105775-02 Glass Door Assy - 41" 1
42 104490-02CJ Baffle - 37" 1
104490-01CJ Baffle - 41" 1
43 104576-02CK Front Assembly - 37" 1
104576-03CK Front Assembly - 41"
44 104615-02 Insulation - 37" 1
105628-01 Insulation - 41" 1
45 104313-01 Hinge, Pin 1
46 104313-02 Hinge, Pin 1
47 104954-01 Screw 3
48 104963-01 Washer 3
49 104955-01 Nut 3
50 103769-01 Duplex Outlet 1
51 104602-01 Duplex Outlet Cover 1
GA6060 Lava Rock 1
104529-01 Ember Material 1
104512-01 Ball Valve 1
KEY
NO.
PART NUMBER DESCRIPTION QTY.
PARTS AVAILABLE - NOT SHOWN
