Thank you for choosing the Sonodyne
RS 650. In gardens and poolsides,
where wall mounting speakers are
not an option, and a minimalistic
look is desired, the unique rock
speaker, the RS 650 is a perfect fit.
Moulded from FRP (fibre reinforced
plastic) the RS 650 enclosure
resembles a rock and has a high
grade 6 " coaxial transducer with
exceptional sound quality. It is 100%
waterproof and has 100V
connectivity option
DESCRIPTION Waterproof garden speaker
ENCLOSURE FRP
SPEAKER 6.5" coaxial pp
RATED POWER 15W/ 25W taps at 100V
COLOUR CODED WATTAGE TAPS White: 15W, 667 Ohm, Green: 25W, 400 Ohm, Black: COM
SENSITIVITY 1W/ 1M 88dB
FREQUENCY RESPONSE (-3 dB) 120 ~ 16 kHz
FREQUENCY RANGE (-10 dB) 80 ~ 18.5 kHz
SPEAKER TERMINAL 3-core cables
DIMENSIONS (HxWxD) 450 x 280 x 300 mm
WEIGHT 5 Kg
DESCRIPTION
ENCLOSURE
SPEAKER
RATED POWER
COLOUR CODED WATTAGE TAPS
SENSITIVITY 1W/ 1M
FREQUENCY RESPONSE (-3 dB)
FREQUENCY RANGE (-10 dB)
SPEAKER TERMINAL
DIMENSIONS (HxWxD)
WEIGHT
SPECIFICATIONS
STEP 1:
Find a strip of hard soil
on the grass/ ground.
Dim: 250 x 375 x 290 mm
STEP 2:
Place the rock speaker
carefully on the ground
STEP 3:
Fix the rock speaker to the
ground with the screws
provided
STEP 4:
After installation,
complete the
connections with
100V lines
