KEY PART NUMBER
NO. VI33NR VI33PR DESCRIPTION QTY.
1 102785-03 102785-03 Log, Golden Oak 1
2 103779-01 103778-01 ODS Pilot 1
3 098249-01 098249-01 ODS Nut 2
4 099387-14 099387-09 Pilot Tube 1
5 111331-13 104229-03 Burner Outlet Tube 1
6 111124-01 111124-01 Burner Retainer Spring 1
7 099056-26 099056-19 Burner Orifice Injector 1
8 102772-01 102772-01 Burner 2
9 M11084-38 M11084-38 Screw, #8 x .38 2
10 104236-01CK 104236-01CK Painted Base Assy 1
11 M12461-26 M12461-26 Screw, #10 x .32 4
12 ** ** Firebox Bottom 1
13 103284-03 103284-03 Wiring Harness 1
14 098265-02 098265-02 Elbow, Male 1
15 103782-01 103782-01 Valve Bracket 1
16 103781-01 103781-02 Gas Control Valve 1
17 098271-10 098271-10 Ignitor Cable 1
18 102445-01 102445-01 Piezo Ignitor 1
19 098304-01 098304-01 Screw 7
20 099998-01 099998-01 Switch 1
21 104241-01 104241-01 Remote Switch Bracket 1
22 103587-01 103587-01 Switch Plate 1
23 097809-02 097809-02 Male Connector 1
24 101628-03 101628-03 Flexible Connector (Hose) 1
25 M50104-02 M50104-02 Bushing 1
26 M11084-26 M11084-26 Screw, #10 x .38 4
27 099918-02
____
Pilot Regulator 1
28 099387-12
____
Pilot Tube (Valve to Regulator) 1
PARTS AVAILABLE — NOT SHOWN
103877-01 103877-01 Lighting Instruction Plate 1
100563-01 100563-01 Warning Plate 1
** Not a field replacement part.
PARTS LIST
This list contains replaceable parts used in your fireplace insert.
When ordering parts, follow the instructions listed under Replace-
ment Parts on page 25 of this manual.
PARTS LIST
Models VI33NR and VI33PR
