380 D Digital to Analog Converter
____________________________________________________________________________________
14
Specifications
Configuration .................................................... Balanced Differential, Stereo
Digital / Analog Power Supply Transformers ......... 25VA / 10VA
Power Supply Capacitance ................................. 26,400µF
Digital Filter / Digital-to-Analog Converters ........... ESS ES9016 Sabre
32 32-bit Hyperstream™
Frequency Response (full range) ......................... 2Hz - 100kHz +0/-3dB
THD @1kHz, 0dBFS (A-weighted) ......................... < 0.001%
Intermodulation Distortion ................................. < 0.001%
Dynamic Range ................................................. > 120dB
Signal-to-noise Ratio .......................................... > 120dB @ full output
Slew Rate ......................................................... 50V/µs
Channel Separation ........................................... > 116dB
Low Level Linearity ............................................ < ±0.25dB at -90dBFS
Intrinsic Jitter .................................................... 1 picosecond RMS
Analog Outputs – Balanced ................................ 1 pair XLR – Fixed Level
Analog Outputs – Single Ended ........................... 1 pair RCA – Fixed Level
Max. Analog Output @ 0dBFS - XLR / RCA ......... 2.0 Volts – Fixed Level
Optional Analog Outputs – Balanced ................... 1 pair XLR – Variable Level
Optional Analog Outputs – Single Ended ............. 1 pair RCA – Variable Level
Max. Analog Output @ 0dBFS - XLR / RCA ......... 4.0 Volts – Variable Level
Analog Output Impedance - XLR / RCA ............. 100 Ω
DSD Data Rates ................................................. (2.8224MHz), Double (5.6448MHz) and
Quadruple (11.2896)
DSD Sample Rates .............................................. DSD 64, DSD 128 & DSD256 via USB only
PCM Bit-depth range ........................................... 16 - 32 bits (32-bit via USB only)
PCM Sampling Frequency Rates............................ 44.1 - 384kHz (352.8 & 384kHz via USB only)
Digital Inputs (8)................................................ 2 x AES/EBU , 3 x S/PDIF, 2 x TosLink, 1 x USB
Digital Outputs (1) ............................................. S/PDIF
Digital Monitor Loop ........................................... S/PDIF - 1 input / 1 output
Remote Control ................................................. Full-Function CRM-2
Power Consumption @ idle ................................. 10 watts
AC Power Requirements ..................................... 120V / 60Hz or 240V / 50Hz
Shipping Weight ................................................ 16 lbs / 7.5 Kgs
Dimensions (W x H x D, inches) .......................... 16.9 x 3.4 x 13.1
Balanced Pin Assignment:
Pin
1 ............................. Ground
Pin 2 ............................. Positive
Pin 3 ............................ Negative
Optional MiND Music Streamer:
Signal Input – Wired ........................................... 100Base-T RJ45 Ethernet interface
Signal Input – Wireless ....................................... IEEE 802.11 b/g/n Wi-Fi interface
NOTE: If you require the RS-232 codes for your Nēo 380D, please visit the "Contact Us" page
and complete the "Information request" form on our website at www.simaudio.com.
Fuse Replacement: For the 120V version use a 0.2A slow blow (5 x 20mm size).
For the 230V version use a 0.1A slow blow (5 x 20mm size).
