Simaudio 760A Amplifier - Manual (Page 13)

760A Dual-Mono Power Amplifier
____________________________________________________________________________________
13
Specifications
Configuration ................................................ Dual Mono
Power Supply Transformers ............................ 2 x 0.5kVA
Power Supply Capacitance ............................. 80,000µF
Class Of Operation ........................................ A/AB
Design ........................................................... Fully Balanced Differential to output stage
Input Impedance .......................................... 47,500
Ω
Input Sensitivity ............................................ 900mV
Output Device Type ....................................... Bipolars - 4 per channel
Output Power at 8
Ω ...................................... 130 Watts per channel
Output Power at 4 Ω ..................................... 260 Watts per channel
Output Power – Bridged Mono at 8 Ω ............... 500 Watts
Frequency Response ...................................... 10Hz - 200kHz +0/-3dB
Output Impedance ........................................ 0.03
Ω
Damping Factor (static) ................................ 267
Gain ............................................................. 31dB
Signal-to-noise Ratio ..................................... > 104dB @ full power
Maximum Output Voltage ............................... 37 Volts
Slew Rate ..................................................... 35V/µs
Maximum Current – Peak ............................... 32 amperes
Maximum Current – Continuous ...................... 20 amperes
Crosstalk @ 1kHz .......................................... -102dB
Intermodulation Distortion ............................. Unmeasureable
THD (20Hz - 20kHz @ 1 watt) ....................... < 0.015 %
THD (20Hz - 20kHz @ 130 watts) .................. < 0.04 %
Power Consumption @ idle ............................. 35 Watts
AC Power Requirements ................................. 120V / 60Hz or 240V / 50Hz
Shipping Weight ............................................ 45 lbs / 20 Kgs
Dimensions (W x H x D, inches) ..................... 18.75 x 4.0 x 18.1
Balanced Pin Assignment:
Pin
1........................... Ground
Pin 2........................... Positive
Pin 3 .......................... Negative
12 Volt Trigger: Logic........................... Direct (0V off, 12V on)
Jack............................
3.5mm microphone jack
Input Impedance ......... 1k Ω
Current Consumption ... 12mA
NOTE: If you require the RS-232 codes for your 760A, please visit the "Contact Us" page
and complete the "Information request" form on our website at www.simaudio.com.
Fuse Replacement: For the 120V version use a 6A fast blow (3AG size).
For the 230V version use a 3A fast blow (3AG size)
