Rupert Neve Portico 5045: Primary Source Enhancer - Manual (Page 9)

9
Depth:
Continuously variable from 0 to 20dBu.
Time Constants:
RMS Mode:
A: 50mS
B: 100mS
C: 200mS
D: 750mS
E: 1.5S
F: 3S
* RMS Mode Time Constant data collected using 10dB bursts.
Peak Mode:
Attack: fixed 20mS
Release:
A: 20mS
B: 200mS
C: 1S
D: 2S
E: 5S
F: 30S
Maximum Output Level: +25dBu
Total Harmonic Distortion and Noise:
@ 1kHz, +20dBu output level, no load
Main Output, feedback suppressor bypassed: Better than 0.002%
Main Output, feedback suppressor engaged: Better than 0.002%
Noise:
Measured @ Main Output, un-weighted, 22Hz-22kHz, 50 ohm terminated input.
Feedback suppressor bypassed Better than -100dBu
Feedback suppressor engaged Better than -95dBu
Frequency Response:
Main Output @ 20Hz -3dB
@150kHz -3dB
Crosstalk
Measured Channel to Channel Better than -80dB @ 16kHz
Power requirements:
12V DC Input
1 Amp
