RTA Products RTA-8107 - Manual (Page 5)

RTA-8107 P.5
2
1
1
2
SCREWS SCREWS
4PCS
6X50 MM B
8
6
SCREWS SCREWS
4PCS
4X14 MM E
1
4
4
1
A B
SCREWS SCREWS
2PCS
6X60 MM C
SCREWS SCREWS
1PC
6X35 MM A
A B
2
3
4
8
8
A
A
Use Screws (B) to fix the Back
Structure (9) between the
Left & Right Back Legs (1&2).
Use Screws (E) to fix the Small Leg (6) to the Bottom Panel.
Use Screws (C ) to fix the
Bottom Panel between
the Left Back Leg and
Left Front Leg (1&4).
Use the Screw (A) to fix
the Bottom Panel to the
Vertical Tube (7).
C
C
